Hot Pressed Boron Carbide Nozzle With Jacket For Injection Machinery

  • 1
  • 2
  • 3

Brand Name : High Broad

Model Number : boron carbide nozzle

Certification : ISO

Place of Origin : China

MOQ : 10 pcs

Price : TBA

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 500000PCS each year

Delivery Time : 7-30 days

Packaging Details : each nozzle in plastic tube then export carton

Material : Boron Carbide

Process : Hot pressed

Keywords : Hot pressed B4C Nozzles and Liner

Other : Boron Carbide Venturi Sand Blasting Nozzles With Jacket For Cleaning The Surface

Advantage : Wear-resistant Venturi blasting nozzles made of Silicon carbide/boron carbide (B4C)

Service : Customized

Contact Now

Boron Carbide/silicon Carbide Venturi Sand Blasting Nozzles With Jacket For Cleaning The Surface

Boron carbide :

Density 2.48g/cm3
Micro degree >3500 kgf/mm
Bending strength >400MPa
Melting point 2450 C
Woking conditions High temperature, high pressure, grinding, acid and alkali
Common application Injection machinery, sealing, drawing, casting, plates, armor, nuclear industry etc.

Specification:
Grind resistant, do not active with acid, low & high temperature resistance,
The density> =2.48g/cm3;
Hardness> =3500kgf/sqm, bending resistance: ≥ 400Mpa
Melting point: 2450degree
And now boron carbide nozzle is instead of hardness alloy, Tungsten carbide nozzle, silicon carbide sandblasting nozzle.
The working life of boron carbide nozzle is 500-1000H
The size can be customized as per drawing

Jacket Type: Aluminum,MS,Nylon jackets,Stainless Steel

Type No. ID(mm) OD (mm) Length(mm)
B4C LINER 4,6,8,10 20 35
4,6,8,10 20 45
4,6,8,10 20 55
4,6,8,10 20 60
6,8,10 20 80

Approximate Nozzle Service Life in Hours :

Nozzle material Steel Shot and Grit Expendable Abrasives Aluoxide Abrasives
Alumina 20-40 10-30 1-4
Tungsten Carbide 500 - 800 300 - 400 20-40
Silicon carbide 600-1000 400-600 50-100
Boron Carbide 1500 - 2500 750 - 1500 200 -1000


We can design and produce various shapes and sizes of boron carbide nozzles, please feel free to contact us if you have any question or inquiry. We will be glad to quote and service you
